MIRLE
_jfif.jpg)
_jfif.jpg)
Injection Molding Machine Controller
MH-6117
Features
​
-
Display unit CPU: ARM9 266MHz 32 bits
-
Control unit CPU: RISC 140MHz 32 bits
-
7-4-inch 800 x 480 TFT LCD long screen, LED backlight
-
6 ranges PID temperature control (control accuracty 1°C)
-
4 sets of transducer input (16 bit)
-
3 sets of D/A proportional valve output (16 bit)
-
32/32 Point digital Input/Output
MH-9118
Features
​​
-
Display unit CPU: ARM9 266MHz 32 bits
-
Control unit CPU: RISC 140MHz 32 bits
-
8.4 inch 800 x 600 TFT LCD
-
8 ranges of PID temperature control (control accuracy 1°C)
-
6 sets of transducer input (16 bit)
-
4 sets of D/A proportional valve output (16 bit)
-
32/32 Inputs/Output (expandable to 48/64 points)
MIRLE
Injection Molding Machine Controller
MH-9110
Features
​
-
Display unit CPU : ATOM 1.6G
-
Control unit CPU: multi-CPU architecture
-
10.4 inch 1024 768 TOUCH TFT LCD
-
5-25 ranges PID Temperature control and 5-25 segments of temperature sensor input [5 Input/module *5 modules-25 input per system, control accuracy 0.5°C]
-
.6-24 Mixed potential Meters (Transducer) input andpressure transducer (A/D) input. [6 Input/module "4 modules=24 input per system, 16 bit]
-
4-16 Proportional Valve D/A output [4 output/module "4 modules=16 outputs per system, 16 bit) 16-128 points of DC24V Input(DI) [16 points/module *8 modules=128 points per system]
-
16-128 points of DC24V output (DO) [16 points/module *8 modules-128 points per system)
MQ-2000
Features
​​
-
Display unit CPU: ATOM 1.6G
-
Control unit CPU: multi-CPU architecture
-
10.4(Vertical) inch 1024* 768 TOUCH TFT LCD
-
5-25 ranges PID Temperature control and 5-25 segments of temperature sensor input [5 Input/module *5 modules=25 input per system, control accuracy 0.5°C]
-
6-24 Mixed potential Meters (Transducer) input and
-
pressure transducer (A/D) input. [6 Input/module *4 modules=24 input per system, 16 bit]
-
4-16 Proportional Valve D/A output [4 output/module *4 modules=16 outputs per system, 16 bit)
-
16-128 points of DC24V Input (DI) [16 points/module *8 modules=128 points per system]
-
16-128 points of DC24V output (DO) [16 points/module
-
*8 modules=128 points per system]
Production Information System
-lg.jpg)
MWeb-10/20/30 production information networking device
Features
​
MWeb-10/20/30 production information networking device
​
• Regional information integration:
The product integrates the current status of the factory machines and records production information immediately for executives to refer
​
• Global information connectivity:
The product has built-in Web-Server function, so managers can monitor or analyze production information with the browser in any PC or hand-held wireless device from anywhere in the world.
​
• Historical production records back up:
With built-in SQL database processing capability, SPC data can be recorded and presented through web query for managers or engineers to perform analysis.
​
• The establishment of a dedicated Web system :
In-house MIS people can build intranet web pages with HTML for different Manufacturing processes.
​
• Remote Diagnosis :
Maintenance personnel can monitor and maintain injection molding machines through internet. The efficiency can be improved and the cost can be reduced.
MIRLE
Linear Transducer - GEFRAN
Features
​
-
Made in Italy
-
Available from 100mm to 900mm
-
Measures the definite position
-
Extensive lifespan
-
High resolution output signal
-
Easy installation and simple connection
-
Road type & Slider type
Computerized Servo Control
ESS-The Energy Saving System of INJECTION MOLDING MACHINE
Features
​​
-
Energy Saving
-
Safety
-
Precision
-
Durability
-
Integrity
